Automatic High Production (250+P.P.H.) Precision Tube Roll


Introduction


CHALLENGE

Design a High Production, High Precision, Fully Automatic tube roller that can be used to roll the most challenging tubes to the highest tolerances.  The roll needs to auto-feed the perforated sheets 2 at a time, and C.N.C. 2-roll tubes perfectly round with touch at the mating seams.  This level of precision must be accomplished at a rate of 250+ Parts Per Hour. Store the programs in the HMI for easy recall.

SOLUTION

Weldlogic Electrical Engineering & Mechanical Engineering collaborated to design the ultimate AC Servo Driven 2 roll with auto-feeder, auto-roll, and auto-eject. The design cleverly offers different durometer urethane to roll a wide range of different materials.
